PAGE 9
Mist Elimi na tor Fil ter in In take Hood (2HP)
Ex ter nal Static Pres sure (in wa ter)
0 0.25 0.5 0.75 1 1.25 1.5
CFM
1200 1100 1225 1315 1405 1440 1695 1725
1400 1220 1275 1400 1480 1620 1730 1790
1600 1225 1345 1475 1615 1715 1775 1890
1800 1335 1465 1610 1710 1765 1880 1930
2000 1380 1585 1680 1755 1815 1920 N/A
SUP PLY
Blower RPM for XAWS20
EXHAUST
Notes:
1. Drive losses included in the above tables.
2. Performance can vary depending on ambient conditions
3. Blower RPMs are for reference only RPM Range
Low 1000-1300 Stan dard Unit
Me dium 1300-1700 Op tional Kit
High 1700-2080 Op tional Kit
SUP PLY
Blower RPM for XAWS11
EXHAUST
Notes:
1. Drive losses included in the above tables.
2. Performance can vary depending on ambient conditions
3. Blower RPMs are for reference only RPM Range
Low 1000-1300 Stan dard Unit
Me dium 1300-1750 Op tional Kit
High 1750-2200 Op tional Kit
Ba ro met ric Hood, 2" Pleated Fil ters ( 1.5HP)
Ex ter nal Static Pres sure (in wa ter)
0 0.25 0.5 0.75 1 1.25 1.5
CFM
300 N/A 1075 1180 1290 1445 1565 1645
500 N/A 1170 1285 1375 1470 1605 1725
700 1065 1280 1370 1465 1600 1680 1800
900 1255 1360 1460 1590 1675 1755 1865
1100 1445 1455 1585 1670 1750 1860 1935
Mist Elimi na tor Fil ter in In take Hood ( 1.5HP)
Ex ter nal Static Pres sure (in wa ter)
0 0.25 0.5 0.75 1 1.25 1.5
CFM
300 N/A N/A 1075 1280 1390 1535 1635
500 N/A 1065 1275 1355 1505 1615 1670
700 1060 1270 1370 1525 1610 1660 1790
900 1310 1455 1520 1605 1655 1820 1960
1100 1445 1515 1625 1725 1815 1955 2035
Ba ro met ric Hood, 2" Pleated Fil ters ( 2HP)
Ex ter nal Static Pres sure (in wa ter)
0 0.25 0.5 0.75 1 1.25 1.5
CFM
1200 1045 1170 1380 1475 1635 1720 1805
1400 1115 1330 1470 1570 1725 1745 1850
1600 1320 1460 1565 1680 1790 1840 1940
1800 1415 1560 1725 1780 1885 1930 2045
2000 1490 1660 1770 1875 1920 1985 N/A
