Reznor XAWS Unit Installation Manual - Manual (Page 10)

PAGE 10
Mist Elimi na tor Fil ter in In take Hoo d (3HP)
Ex ter nal Static Pres sure (in wa ter)
0 0.25 0.5 0.75 1 1.25 1.5
CFM
2000 820 930 1015 1095 1160 1245 1315
2400 920 1010 1090 1155 1240 1305 1405
2800 1000 1085 1150 1235 1295 1410 1500
3200 1130 1200 1260 1395 1430 1495 1565
3600 1190 1385 1420 1455 1510 N/A N/A
SUP PLY
Blower RPM for XAWS36
EXHAUST
RPM Range
Low 700-1025 Stan dard Unit
Me dium 1030-1305 Op tional Kit
High 1325-1575 Op tional Kit
SUP PLY
Blower RPM for XAWS28
EXHAUST
RPM Range
Low 950-1320 Stan dard Unit
Me dium 1325-1565 Op tional Kit
High 1570-1880 Op tional Kit
Mist Elimi na tor Fil ter in In take Hood (3HP)
Ex ter nal Static Pres sure (in wa ter)
0 0.25 0.5 0.75 1 1.25 1.5
CFM
1200 N/A N/A 985 1115 1255 1390 1445
1600 N/A 975 1090 1190 1320 1320 1525
2000 960 1085 1185 1315 1410 1410 1550
2400 1080 1240 1310 1405 1485 1485 1650
2800 1230 1395 1505 1535 1595 1595 1775
Ba ro met ric Hood, 2" Pleated Fil ters (3HP)
Ex ter nal Static Pres sure (in wa ter)
0 0.25 0.5 0.75 1 1.25 1.5
CFM
1200 N/A N/A 1050 1210 1315 1375 1465
1600 N/A 1020 1200 1285 1365 1465 1545
2000 1010 1190 1320 1355 1540 1580 1660
2400 1155 1315 1425 1545 1660 1735 1785
2800 1290 1450 1600 1725 1755 1825 1880
Notes:
1. Drive losses included in the above tables.
2. Performance can vary depending on ambient conditions
3. Blower RPMs are for reference only
Notes:
1. Drive losses included in the above tables.
2. Performance can vary depending on ambient conditions
3. Blower RPMs are for reference only
Ba ro met ric Hood, 2" Pleated Fil ters (3HP)
Ex ter nal Static Pres sure (in wa ter)
0 0.25 0.5 0.75 1 1.25 1.5
CFM
2000 780 890 970 1065 1130 1235 1275
2400 885 965 1060 1125 1230 1270 1340
2800 945 1055 1120 1225 1265 1355 1405
3200 1050 1135 1255 1325 1350 1415 1460
3600 1125 1250 1305 1340 1415 N/A N/A
