— Parts List —
Item
No.
Description
12" fan size 16" fan size 20" fan size
5 & 7.5 kW 10 kW 15 & 20 kW 25, 30 & 35 kW
1 Core assembly ( with bus bars) Specify Voltage, phase, and kilowatts ( V-Ph-kW)
2 Bottom panel RZ235459 RZ235477 RZ235490
3 Left side panel RZ235460 RZ235478 RZ235491
4 Louver blades RZ235461 RZ235479 RZ235492
5 Top panel RZ235462 RZ235480 RZ235493
6 Right side panel RZ235463 RZ235481 RZ235494
7 Fan panel RZ235464 RZ235482 RZ235495
8 Fan blades
5.0 kW = RZ235451
7.5 kW = RZ235452
10.0 kW = RZ235453
15.0 kW = RZ235454
20.0 kW = RZ235455 25.0 kW = RZ235456
30.0 & 35.0 kW = RZ235457
9 Fan guard (2 pieces) RZ235465 RZ235483 RZ235496
10 Motor, explosion-proof
115/208-230V, 1Ø, 60Hz = RZ235446
208-230/460V, 3Ø, 60Hz = RZ235447
575V, 3Ø, 60Hz = RZ235449
208-230/460V, 3Ø, 60Hz = RZ235448
575V, 3Ø, 60Hz = RZ235450
11 Right side motor bracket RZ235458
12 Motor base RZ235466 RZ235484 RZ235497
13 Left side motor bracket RZ235473
14 Expansion union, female RZ235474
15 Conduit, expansion union to elbow RZ235467 RZ235485 RZ235498
15A Reducing bushing RZ235475
16 Thermostat, ex-proof RZ234436, (CX1 ex-proof wall thermostat)
16A Elbow, 90° RZ235476
17 Conduit, potted
RZ235468 with thermostat
RZ235469 without thermostat
RZ235500 with thermostat
RZ235501 without thermostat
18 Conduit, vertical RZ235470 RZ235486 RZ235499
19 O-ring, element enclosure cover RZ235488
20 Cover, element enclosure RZ235489
21 Guard, element enclosure RZ235504
22 Conduit, motor box to enclosure RZ235471 RZ235502
22A Union RZ235505
23 Box, motor outlet RZ235506
23A Conduit, motor to motor box RZ235472 RZ235487 RZ235503
24 Enclosure, control RZ235507
25 Contactor 120V = RZ235508, 24V = RZ235509
26 Transformer 120V = RZ235510, 24V = RZ235511
27 Bracket, Transformer ground RZ235512
28 Grounding lug RZ235513
29 Fuse 120V = 1/4 Amp (RZ235514), 24V = 1 Amp (RZ235515)
30 Printed circuit board assembly 120V = RZ235516, 24V = RZ235517
31 High limit, automatic reset RZ235518 (also requires Part # RZ235519)
32 Conductive cement, high limit RZ235519
33 Bracket, transformer RZ235520
34 O-ring, control enclosure cover RZ235521
35 Cover, control enclosure RZ235522
36 Plug, 3/4” NPT explosion-proof RZ235523
37 Nut, bus bar RZ235524
38 Bus bar, long straight RZ235525
39 Bus bar, short straight RZ235526
40 Bus bar, short curved RZ235527
41 Bus bar, long curved RZ235528
42 High limit, manual reset RZ235529 (also requires Part # RZ235519)
43 Handle, Disconnect RZ235530
44 Switch, Disconnect 60A Non-Fused RZ235531
