• To make the proper selection in the Electronic Vehicle Information Center (EVIC),

press the UP or DOWN steering wheel buttons until “VEHICLE SETTINGS”

displays. For additional information, refer to Electronics in this guide.

• Press the RIGHT arrow on the steering wheel to enter “VEHICLE SETTINGS.”
• Press the UP or DOWN buttons until Trailer Brake Type appears on the screen.
• Press the RIGHT arrow and then press the UP or DOWN buttons until the proper

Trailer Brake Type appears on the screen.

GAIN Adjustment Buttons (+/-)

• Pressing the +/- buttons, located on

the left side of the module, will
increase/decrease the brake control
power output to the trailer brakes in
0.5 increments. The GAIN setting can
be increased to a maximum of 10 or
decreased to a minimum of 0 (no
trailer braking).

• Refer to your Owner's Manual on the

DVD for further details.

WARNING!

Connecting a trailer that is not compatible with the ITBM system may result in
reduced or complete loss of trailer braking. There may be a increase in stopping
distance or trailer instability which could result in personal injury.

UTILITY

119
