PS Engineering
PMA7000H Audio Selector Panel and Intercom System
Installation and Operator’s Manual
200-780-0429 Page 3-4 Rev. 4, Dec 2012
Table 3-1 Mic Muff ™ Part Numbers
Manufacturer Model Mic Muff™ Part Number
Bose Dynamic
Electret
M87 Dynamic
90010
90015
90020
David Clark H10-30
H10-20, H10-40
H10-13.4
90010
90015
90015
Lightspeed 15K & 20K 90015
Peltor 7003
7004
90010
90015
Pilot 11-20 & 11-90 90015
Sennheiser 90015
Telex Airman 750
AIR3000
90015
90010
3.6.2 Intercom Volume Control
The inner volume control knob adjusts the loudness of the intercom for the pilot and copilot. It has no effect
on selected radio levels, music input levels or passengers' volume level.
The outer volume control knob controls intercom volume or the passengers. It has no effect on radio or mu-
sic levels.
Adjust the radios and intercom volume for a comfortable listening level. Most general aviation headsets
today have built-in volume controls; therefore, volume also can be further adjusted at the individual head-
set.
3.6.2.1 Mono headsets in Stereo Installation
All passenger headsets are connected in parallel. Therefore, if a monaural headset is plugged in to a
PMA7000H Stereo installation, one channel will be shorted. Although no damage to the unit will occur, all
passengers will lose one channel, unless they switch to the “MONO” mode on the headset. PS Engineering
modifies headsets to add stereo capability, using high-fidelity speakers. Contact factory for details.
3.6.3
Intercom Modes
The lower switch on the left side is a 3-position mode switch that allows the pilot to tailor the intercom
function to best meet the current cockpit situation. The description of the intercom mode function is valid
only when the unit is not in the "Split" mode. Then, the pilot and copilot intercom is controlled with the ICS
button.
I
SO : (Up Position): The pilot is isolated from the intercom and is connected only to the aircraft radio sys-
tem. He will hear the aircraft radio reception (and sidetone during radio transmissions). Copilot will hear
passengers’ intercom and Entertainment 1, while passengers will hear copilot intercom and Entertainment 2.
Neither will hear aircraft radio receptions or pilot transmissions.
A
LL : (Middle Position): All parties will hear the aircraft radio and intercom. Crew will hear Entertainment
1, passengers will hear Entertainment 2. During any radio or intercom communications, the music volume
automatically decreases. The music volume increases gradually back to the original level after communica-
tions have been completed.
C
REW (Down Position): Pilot and copilot are connected on one intercom channel and have exclusive access
to the aircraft radios. They may also listen to Entertainment 1. Passengers can continue to communicate
with themselves without interrupting the Crew and also may listen to Entertainment 2.
