MBOX ® MEDIA SERVER USER MANUAL 215
Note that each Aspect Control range is a ratio applied
over the native aspect ratio of the file. e.g. 1:1 x 4:3 = 4:3
Aspect Control
Values Mode
0 Default Ratio
1-126 Ratios scaling from 1:4 to 1:1
127 Default Ratio
128-255 Ratios scaling from 1:1 to 4:1
Sync Stream
Values Mode
0 Layer to Layer Stream (default)
1-16 Stream Number
Frame Blending Control
Values Description
0 No Frame Blending (more accurately, blend time = 0)
1-255
Variable Frame Blend Time, as a proportion of the
frame time. This is a square-law control, and 50%
blend time is achieved at value 210, 25% blend time
at value 165
Play Mode
Values Play Mode
0 Forward Loop
1 Forward Loop, Pause when Layer Opacity = 0
2
Forward Loop, Pause and Reset to In-Point
when Layer Opacity = 0
10 Reverse Loop
11 Reverse Loop, Pause when Layer Opacity = 0
12
Reverse Loop, Pause and Reset to In-Point
when Layer Opacity = 0
20 Forward Once
21 Forward Once, Pause when Layer Opacity = 0
22
Forward Once, Pause and Reset to In-Point
when Layer Opacity = 0
30 Reverse Once
31 Reverse Once, Pause when Layer Opacity = 0
32
Reverse Once, Pause and Reset to In-Point
when Layer Opacity = 0
40-49 Forward Bounce
50-59 Reverse Bounce
60-69 Random
70-79 Forward Once - Restart on In Frame Change
80-89 Scrub - In Frame
90-99 Scrub - Out Frame
100-109 Forward Loop - Crossfade on Out Frame
110-119 Reverse Loop - Crossfade on In Frame
120-129 Forward Loop - Restart on In Frame Change
130-134 Timecode Sync (Strict Lock)
135 Timecode Sync then Freewheel
136 Timecode Jam Sync
140 - 149 Layer Slave
150 - 159 Layer Master - Forward Loop
160 - 169 Layer Master - Forward Once
180
Kiosk Mode Non-Looping, pause on last
frame of last file
181 Kiosk Mode Non-Looping -loop last file
182 Kiosk Mode Non-Looping - fade out last file
185 - 189 Kiosk Mode Looping
190 - 199 SMPTE Kiosk Mode
240 Playout Mode - last 5 seconds
241 Playout Mode - last 10 seconds
242 Playout Mode - last 15 seconds
243 Playout Mode - last 20 seconds
244 Playout Mode - last 30 seconds
250-255 Restart Movie from In Point
