176 MBOX ® MINI USER MANUAL
Frame Blending
Values Description
0 No Frame Blending (more accurately, blend time = 0)
1-255
Variable Frame Blend Time, as a proportion of the
frame time. This is a square-law control, and 50%
blend time is achieved at value 210, 25% blend time
at value 165.
Video Input and Utility (Texture Folder 255)
Texture
Value
Input
0 Patch Info Display
121 Layer Copy FX+ Layer 1
122 Layer Copy FX+ Layer 2
123 Layer Copy FX+ Layer 3
124 Layer Copy FX+ Layer 4
201 Syphon Input 1
202 Syphon Input 2
240 CG Color bars
254 Video Input 2
255 Video Input 1
TC DMX Control
The TC DMX controls are only required when the TC
DMX Control feature has been configured. (Refer to
"TC
DMX Controls" on page 65.) Each item in the TC DMX
Controls preference relates to one fixture that must be
patched to control timecode on a layer.
Chan Size Function Default Snap
1 1 Hours (0-23) 255 N
2 1 Minutes (0-59) 255 N
3 1 Seconds (0-59) 255 N
4 1 Frames (0-29) 255 N
