MBOX ® MINI USER MANUAL 171
Summary: Single Output
Start Size Type Universe
1 11 Master
1st
190 Total
Channels
12 8 Keystone
20 14 Shutter
34 39 Layer 1
73 39 Layer 2
112 39 Layer 3
151 39 Layer 4
Summary: Dual Output - Panoramic Wide
Start Size Type Universe
1 11 Master
1st
190 Total
Channels
12 8 Keystone
20 14 Shutter
34 39 Layer 1
73 39 Layer 2
112 39 Layer 3
151 39 Layer 4
Parameter Descriptions
Fixture Parameter Description
Master
Pixel Map
Level
Intensity master for pixel-
mapping Art-Net output
Pixel Map
Control
Control functions for pixel-
mapping
Texture
Effect 1
2D effect applied to the final
Modifier 1a First modifier
Modifier 1b Second modifier
Red Red subtractive
Green Green subtractive
Blue Blue subtractive
Intensity Intensity of the video output
Control
Control functions for server -
HUDs, macros, etc.
Master
Audio
Volume
Final output volume master
Keystone
Keystone 1a
Bottom-Left X or X Rotation
Coarse
Keystone 1b
Bottom-Left Y or X Rotation
Fine
Keystone 2a
Bottom-Right X or Y Rotation
Coarse
Keystone 2b
Bottom-Right Y or Y Rotation
Fine
Keystone 3a Top-Left X or Aspect Coarse
Keystone 3b Top-Left Y or Aspect Fine
Keystone 4a Top-Right X or Curve Y
Keystone 4b Top-Right Y or Curve X
