6

Table 1B — 30MPA Air-Cooled and 30MPW Liquid-Cooled Units — SI

* With optional hot gas bypass.

NOTES:

1. Operating weight includes refrigerant operating charge and

weight of fluid in the heat exchangers.

2. 30MPW units are shipped with full operating charge.

UNIT 30MPA,MPW

015

020

030

040

045

NOMINAL KW

54

71

108

138

161

OPERATING WT (kg)

MPA

284

288

327

414

424

MPW

308

319

391

499

540

REFRIGERANT (kg)

R-410A

MPA

MPW

5.2

6.9

10.5

13.3

15.6

COMPRESSOR

Scroll, Hermetic

Quantity

2

2

2

3

3

Speed (r/s)

58

58

58

58

58

Compressor Nominal kW

26

35

53

45

53

Oil Charge (L)

5.0

6.5

6.5

9.8

9.8

Capacity Control — Standard

No. of Steps

2

2

2

3

3

Minimum Step Capacity (%)

50

50

50

33

33

Capacity Control — Optional Hot Gas Bypass

No. of Steps

3

3

3

4

4

Minimum Step Capacity (%)

18

25

34

21

22

EVAPORATOR

Weight (kg, empty)

12.5

18.3

41.6

55.5

58.2

Net Fluid Volume (L)

2.9

4.6

8.9

12.0

13.0

Maximum Refrigerant Pressure (kPa)

4482

4482

4482

4482

4482

Maximum Fluid-Side Pressure (kPa)

2068

2068

2068

2068

2068

Water Connections (in.)

Inlet and Outlet (Victualic)

2

2

2

1

/

2

2

1

/

2

2

1

/

2

Drain (NPT)

1

/

2

1

/

2

1

/

2

1

/

2

1

/

2

CONDENSER (30MPW)

Weight (kg, empty)

15.8

19.8

47.4

62.0

85.4

Net Fluid Volume (L)

4.5

5.9

11.1

15.4

22.4

Maximum Refrigerant Pressure (kPa)

4482

4482

4482

4482

4482

Maximum Fluid-Side Pressure (kPa)

2068

2068

2068

2068

2068

Water Connections (in.)

Inlet and Outlet (Victualic)

1

1

/

2

1

1

/

2

2

2

2

CHASSIS DIMENSIONS (mm)

Length

1397

1397

1397

1397

1397

Width

813

813

813

813

813

Height

1600

1600

1600

1600

1600

MINIMUM SYSTEM FLUID VOLUME (L per kW)

Normal Air Conditioning
Standard

23

23

23

15

15

Optional Hot Gas Bypass

15

15

15

11

11

Low Outdoor Ambient Cooling Operation (30MPA Units)
Standard

38

38

38

30

30

Optional Hot Gas Bypass

25

25

25

23

23

CAPACITY STEPS

Step 1

100%

100%

100%

100%

100%

Step 2

50%

50%

50%

67%

67%

Step 3

18%*

25%*

34%*

33%

33%

Step 4

21%*

22%*

MINIMUM FLOW RATES (L/s)

Evaporator

1.4

1.8

2.7

3.5

4.0

Condenser

1.4

1.8

2.7

3.5

4.0

MAXIMUM FLOW RATES (L/s)

Evaporator

4.7

6.1

9.3

11.9

13.9

Condenser

4.7

6.1

9.3

11.9

13.9
