NOTE
If no MAC address is entered, the Antenna
Alignment tool will make use of the SSID to align
the antenna. Please ensure that the correct SSID
is entered. If more than one access point share
the same SSID, the access point with the
strongest signal will be shown.
Signal Strength
(RSSI Value) Indicated by DIAG LED
Status of DIAG LED
Above 20
Stays turned on.
Between 19 and 17
Flashes 6 times.
Between 17 and 14
Flashes 3 times.
Between 13 and 10
Flashes once.
Below 10
Turns off.
NOTE
Outdoor long distance connection should
preferably have signal strength of a RSSI of 10 and
above.
NOTE
To ensure proper functionality of the device,
select to Stop antenna alignment.
Alternatively, you may also reboot the device.
