Device Configuration Strategy
The following is a series of ordered events needed to load the
configuration latches on a per channel basis:
1. Pulse RESET Low after device power up. This operation
resets all four channels. Initialize the JTAG state machine to
its reset state as detailed in the
2. Set the static receiver latch bank for the target channel. May
be performed using a global operation, if the application
permits it. [Optional step if the default settings match the
desired configuration.]
3. Set the static transmitter latch bank for the target channel.
May be performed using a global operation, if the application
permits it. [Optional step if the default settings match the
desired configuration.]
4. Set the dynamic bank of latches for the target channel. Enable
the Receive PLLs and transmit channels. May be performed
using a global operation, if the application permits it.
[Required step.]
5. Reset the Phase Alignment Buffer for the target channel. May
be performed using a global operation, if the application
permits it. [Optional if phase align buffer is bypassed.]
When a receive channel is configured with the decoder
bypassed and the receive clock selected as recovered clock in
half rate mode (DECBYPx = 0, RXRATEx = 0, RXCKSELx = 0),
the channel cannot be dynamically reconfigured to enable the
decoder with RXCLKx selected as the REFCLKx (DECBYPx =
1, RXCKSELx = 1). If such a change is desired, a global reset
should be performed and all channels should be reconfigured to
the desired settings.
JTAG Support
The CYV15G0404DXB contains a JTAG port to allow system
level diagnosis of device interconnect. Of the available JTAG
modes, boundary scan, and bypass are supported. This
capability is present only on the LVTTL inputs and outputs and
the REFCLKx± clock input. The high-speed serial inputs and
outputs are not part of the JTAG test chain.
To ensure valid device operation after power up (including
non-JTAG operation), the JTAG state machine must also be
initialized to a reset state. This is done in addition to the device
reset (using RESET). The JTAG state machine is initialized using
TRST (asserting it LOW and de-asserting it or leaving it
asserted), or by asserting TMS HIGH for at least five consecutive
TCLK cycles. This is necessary to ensure that the JTAG
controller does not enter any of the test modes after device
power up. In this JTAG reset state, the rest of the device is in
normal operation.
Note. The order of device reset (using RESET) and JTAG initial-
ization does not matter.
Table 10. Device Control Latch Configuration Table
ADDR
Channel Type
DATA7
DATA6
DATA5
DATA4
DATA3
DATA2
DATA1
DATA0
Reset
Value
0
(0000b)
A
S
RFMODEA[1]
RFMODEA[0]
FRAMCHARA
DECMODEA
DECBYPA
RXCKSELA
RXRATEA
GLEN0
10111111
1
(0001b)
A
S
SDASEL2A[1]
SDASEL2A[0]
SDASEL1A[1]
SDASEL1A[0]
ENCBYPA
TXCKSELA
TXRATEA
GLEN1
10101101
2
(0010b)
A
D
RFENA
RXPLLPDA
RXBISTA
TXBISTA
OE2A
OE1A
PABRSTA
GLEN2
10110011
3
(0011b)
B
S
RFMODEB[1]
RFMODEB[0]
FRAMCHARB
DECMODEB
DECBYPB
RXCKSELB
RXRATEB
GLEN3
10111111
4
(0100b)
B
S
SDASEL2B[1]
SDASEL2B[0]
SDASEL1B[1]
SDASEL1B[0]
ENCBYPB
TXCKSELB
TXRATEB
GLEN4
10101101
5
(0101b)
B
D
RFENB
RXPLLPDB
RXBISTB
TXBISTB
OE2B
OE1B
PABRSTB
GLEN5
10110011
6
(0110b)
C
S
RFMODEC[1]
RFMODEC[0]
FRAMCHARC
DECMODEC
DECBYPC
RXCKSELC
RXRATEC
GLEN6
10111111
7
(0111b)
C
S
SDASEL2C[1]
SDASEL2C[0]
SDASEL1C[1]
SDASEL1C[0]
ENCBYPC
TXCKSELC
TXRATEC
GLEN7
10101101
8
(1000b)
C
D
RFENC
RXPLLPDC
RXBISTC
TXBISTC
OE2C
OE1C
PABRSTC
GLEN8
10110011
9
(1001b)
D
S
RFMODED[1]
RFMODED[0]
FRAMCHARD
DECMODED
DECBYPD
RXCKSELD
RXRATE D
GLEN9
10111111
10
(1010b)
D
S
SDASEL2D[1]
SDASEL2D[0]
SDASEL1D[1]
SDASEL1D[0]
ENCBYPD
TXCKSELD
TXRATED
GLEN10
10101101
11
(1011b)
D
D
RFEND
RXPLLPDD
RXBISTD
TXBISTD
OE2D
OE1D
PABRSTD
GLEN11
10110011
12
(1100b)
GLOBAL
S
RFMODEGL[1]
RFMODE
GL[0]
FRAMCHARGL DECMODEGL DECBYPGL RXCKSELGL RXRATEG
L
FGLEN0
N/A
13
(1101b)
GLOBAL
S
SDASEL2GL[1]
SDASEL2GL[
0]
SDASEL1GL[1] SDASEL1GL[0
]
ENCBPGL
TXCKSELGL
TXRATEG
L
FGLEN1
N/A
14
(1110b)
GLOBAL
D
RFENGL
RXPLLPDGL
RXBISTGL
TXBISTGL
OE2GL
OE1GL
PABRSTG
L
FGLEN2
N/A
15
(1111b)
MASK
D
D7
D6
D5
D4
D3
D2
D1
D0
11111111
