Concord Camera 5330z - Manual (Page 19)

19
3 3 Determine the image composition while looking into the
LCD monitor or viewfinder.
5 5 Press the shutter-release button half-way down.
• When the image is focused, the focus lamp (green) lights up.
4 4 Adjust the image range and size with the four-way keys
( / ).
• When the key is pressed, the image size becomes large.
• When the key is pressed, the image range becomes wide.
6 6 Press the shutter-release button full-way down to take the
picture.
• The captured image is displayed on the LCD monitor.
• While the captured image is recorded in the CF card, the focus lamp (green)
blinks slowly (about 2 times in a second).
