The SOLO 1200 uses 18 DMX channels. They are listed in the following table.
Channel Function DMX Value Description
000-009 Blackout
010-020 Open
021-034 Strobe 1
035-048 Strobe 2
049-062 Strobe 3
063-076 Strobe 4
077-090 Strobe 5
091-104 Strobe 6
105-118 Strobe 7
119-132 Strobe 8
133-146 Strobe 9
147-160 Strobe 10
161-174 Strobe 11
175-188 Strobe 12
189-202 Strobe 13
203-216 Strobe 14
217-230 Strobe 15
231-244 Strobe 16
1 Strobe
245-255 Open
2 Dimmer 000-255 0 to 100% dimming
3 Iris 000-255 Linear adjust iris from open to closed
000-020 Clear
021-040 Gobo 1
041-060 Gobo 2
061-080 Gobo 3
081-100 Gobo 4
101-120 Gobo 5
121-140 Gobo 6
141-160 Gobo 7
161-167 Rotation speed 1 (slowest)
168-175 Rotation speed 2
176-183 Rotation speed 3
184-207 Rotation speed 4 (fastest)
208-231 Reverse rotation speed 1 (slowest)
232-239 Reverse rotation speed 2
240-247 Reverse rotation speed 3
4 Fixed Gobos
248-255 Reverse rotation speed 4 (fastest)
5 Pan rotation 000-255 Pan rotation from 0 to 540º
6 Tilt rotation 000-255 Tilt rotation from 0 to 270º
7 Focus 000-255 Linear adjust iris from near to far
8 Zoom 000-255 Linear adjust angle from narrow to wide
000-016
White.Note: stay 5 seconds while DMX value
is 5, 6or 7, the function reset perform
017-024 White/colour filter 1
9 Colour Wheel
025-032 Colour filter 1
DMX CONTROL CHANNEL FUNCTIONS
