Rize Panel System
161 Tradition Trail, Holly Springs, NC, 27540
800-520-7471 (voice) 919-362-4765 (fax)
919-303-6389 (voice) www.ofminc.com
[email protected]
Align frame with corner
connector and screw in
knobs on each side.
2
For panel to panel connections;
align frames and use smaller
knob, then tighten with
butterfly bolt.
3
Install cables along frame
base through openings.
Pop off grommet and
insert cables.
4
Place panel cover hooks into
frame hooks. Once wires are
adjusted for length, pop on
grommet covers.
5
Attach corner connector to
frame with screw-in knobs.
Set up frames with corner
connector.
1
