OFM 66180 - Manual

Assembly Notes:
During assembly, hand tighten screws only. When all screws
are in place, you may then tighten all screws completely.
CAUTION:
1. Do not use this table as a step ladder.
2. Check for loose screws and tighten them every 6 months.
Model 66180
Mesa Series Half Round Table
Parts Listing
919-362-4765 (fax)
www.ofminc.com
161 Tradition Trail, Holly Springs, NC, 27540
800-520-7471 (voice)
919-303-6389 (voice)
[email protected]
01.15.2014
STOP
Assembly Instructions
Tools Needed: Phillips Head Screwdriver
Please read all instructions before assembly.
Step 1: Place Table Top (A) upside down on a clean, flat surface.
Place the Mobile Legs (B) upside down onto the Table Top (A)
as shown, and attach by inserting 6x16mm Screws (E)
through built-in bracket and into the Table Top (A).
Repeat Step 1 with Stationary Legs (C).
Step 2: Align the holes on the Support Rail (D) with the holes on the
Mobile Legs (B) and insert 6x16mm Screws (E) through the
Support Rail (D) and into the Mobile Legs (B). Repeat Step 2
and attach each Support Rail (D) to the Stationary Legs (C).
Attach each Support Rail (D) to the Table Top (A) by inserting
6x55mm Screws (F) through the center holes of the Support
Rail (D) and into the Table Top (A).
A
Table Top
1 Unit
C
Stationary Legs
1 Unit
D
Support Rail
2 Units
E
6x16mm Screw
24 Units
F
6x55mm Screw
2 Units
B
Mobile Legs
1 Unit
1 2
A
B
C
E
E
F
D
B
