OFM FT42SQ User Manual
Flip top multi-purpose table, Assembly instructions

Holly Springs, NC, USA
800-520-7471 (voice)
919- 303-6389 (voice)
919-362-4765 (fax)
www.ofminc.com
Flip Top Multi-Purpose Table
Model FT36RD 36" Round ▪ Model FT42RD 42" Round
Model FT36SQ 36" Square ▪ Model FT42SQ 42" Square
Assembly Instructions
Step 1: Place Base Mechanism (C) on to flat surface.
Step 2: Latch Base Mechanism (C) in upright position.
Step 3: Slide Metal Insert (D) into groove on base mechanism
and attach Plastic Cap (E).
Step 4: Screw Rod (B) through Metal Insert (D) and Plastic Cap (E)
into Base Mechanism (C).
Step 5: Place Cylinder (A) over Rod (B)
Step 6: Set X-Base (G) through end of Rod (B), place Washer then
Spacer (F) and screw on Bolt (I) tightly.
Step 7: Place Table Top (H) on flat non-scratching surface. Invert base
unit and align with matching holes. Insert and tighten 6 bolts (J).
S
tep 8: Return to upright position. Unhook latch to fold top down.
Use built-in handle to carry table.
Parts List
1 - Cylinder (A)
1 - Rod (B)
1 - Base Mechanism (C)
1 - Metal Insert (D)
1 - Plastic Cap (E)
1 - Washer with Spacer (F)
1 - X-Base (G)
1 - Table Top (H)
1 - Nut for Rod (I)
6 - 6m x 19mm Bolts (J)
B
E
D
C
A
H
G
F
I
J
