OFM N102 User Manual
Model n102, Net swivel chair with gas lift, Assembly instructions

A
Seat
1 Unit
B
Base
1 Unit
C
Gas Lift
1 Unit
D
Seat Bracket with Handle
1 Unit
E
Plastic Cap
1 Unit
F
8x25mm Screw
4 Units
G
8x30mm Screw
3 Units
H
8mm Nut
4 Units
I
Allen Wrench
1 Unit
Assembly Notes:
During assembly, hand tighten screws only. When all screws
are in place, you may then tighten all screws completely.
CAUTION:
1. Do not use this chair as a step ladder.
2. Check for loose screws and tighten them every 6 months.
Model N102
NET Swivel Chair with Gas Lift
WEIGHT CAPACITY: 300 lbs.
Parts Listing
919-362-4765 (fax)
www.ofminc.com
161 Tradition Trail, Holly Springs, NC, 27540
800-520-7471 (voice)
919- 303-6389 (voice)
[email protected]
05.16.2012
G
STOP
Assembly Instructions
Tools Needed: Adjustable Wrench and supplied Allen Wrench
Please read all instructions before assembly.
Step 1: Attach Base (B) to Gas Lift (C) by inserting
8x30mm Screw (G) up through the bottom of the
Base (B) into the Gas Lift (C). Using Allen
Wrench (I) tighten securely.
Step 2: Attach Seat Bracket with Handle (D) to Seat (A) by
aligning the holes between the two. Now insert 8x25mm
Screws (F) under metal mesh of Seat (A) and down
through holes and Seat Bracket with Handle (D).
Attach the 8mm Nuts (H) on the bottom of 8x25mm
Screws (F). Using the Allen Wrench (I), tighten all
screws securely only when all four have been attached.
Step 3: Cover 8x25mm Screws (F) under mesh with
Plastic Cap (E).
Step 4: Place Seat (A) with attached Seat Bracket with
Handle (D) onto the top of the Gas Lift (C). Press
down on Seat (A) firmly to secure.
C
H
D
A
B
E
F
