OFM 595-L User Manual
Assembly instructions

A
Chair Back
1 Unit
B
Chair Seat
1 Unit
C
Chair Base
1 Unit
D
Chair Arms
2 Units
E
Large Washer
2 Units
F
Small Washer
14 Units
G
8x45mm Screw
4 Unit
H
8x25mm Screw
4 Units
I
Arm Screws
6 Units
Assembly Notes:
During assembly, hand tighten screw only when all screws
are in place, you may then tighten all screws completely.
CAUTION:
1. Do not use this chair as a step ladder.
2. Check for loose screws and tighten them every 6 months.
Model 595-F / 595-L
Ultimate Executive Fabric/Leather & Mesh Guest Chair
WEIGHT CAPACITY: 250 lbs.
Parts Listing
STOP
Assembly Instructions
Tools Needed: Phillips Head Screwdriver
Please read all instructions before assembly.
Step 1: Attach Chair Arms (D) to Chair Seat (B) by placing Large Washers (E)
between the Chair Seat (B) and the Chair Arms (D), aligned with the
inside hole on arms. Then with one Small Washer (F) on each Arm
Screw (I), insert screws through the holes in the Chair Arms (D) and
into the Chair Seat (B).
Step 2: Attach Chair Base (C) to Chair Seat (B) by inserting four 8x25mm
Screws (H), with Small Washers (F) through holes in the crossbars of
the Chair Base (C) and into the Chair Seat (B).
Step 3: Attach Chair Back (A) to Chair Seat (B) by inserting three 8x45mm
Screws (G), with Small Washers (F), through bars and into the Chair
Seat (B).
919-362-4765 (fax)
www.ofminc.com
161 Tradition Trail Holly Springs, NC, 27540
800-520-7471 (voice)
919- 303-6389 (voice)
[email protected]
06.14.2010
E
F
B
I
D
1
3
G
F
C
B
A
2
H
F
C
B
