NORAC UC5-BC-HD06 User Manual
Page 36
33
Use the dimensioned drawing below as a guide for drilling the valve block mounting holes for
the LPZ boom. Drill holes large enough to accommodate 3/8” bolts.
See Section 13 for a drilling stencil.
NORAC Valve Block P/N
X
Y
44963D
82.5mm (3.25 in)
111.1mm (4.375 in)
Figure 35: NORAC Valve Block Mounting Hole Dimensions
