PARTS LISTS
The parts that come with your UC4+ Sprayer Boom System are listed in Table 1. The item
number on the left side of this table references each part.
Please ensure that all parts in your kit are present before proceeding with your
installation.
Table 1: UC4+ Spray Height Control System Parts
Item Part Number Name Quantity
B05 44706-01 KIT CABLE TIE BLACK 10 PCS 21 IN 150 PCS 7.5 IN 1
B10 44700-06 BRACKET VALVE MOUNTING STD 1
B11 44743 MOUNTING BRACKET MAIN LIFT SENSOR UC4 PLUS 1
B13 44728 MOUNTING BRACKET COMPLETE UC4 BREAKAWAY EXTENDED 2
C01 44662B-40 CABLE UC3 SENSOR TRUNK AMPF TO AMPF BLACK STANDARD 40FEET 1
C02 44668 CABLE UC3 SENSOR BRANCH 1 AMP RECEPT 3 AMP PLUG BC 1
C02B 44664 CABLE UC4 CAN NODE DUAL 1
C03 44656D CABLE VALVE VARIABLE RATE DT 1
C04 44651 CABLE VALVE EXTENSION 1
C10 44650-11 CABLE POWER UC3 BOOM CONTROL GREGSON MAVERICK 1
E01 4461BC+ UC4 PLUS BOOM CONTROL PANEL 1
E02 44631 UC4 ULTRASOUND SENSOR 3
E03 45000* UC4 PLUS ROLL SENSOR W TEMPERATURE PROBE VER. 2 1
E04 45001* UC4 PLUS ROLL SENSOR VER. 2 1
H03 44863-07 HOSE ASSEMBLY 122R2-06 60 IN L 6FJX 6FJX90 2
H04 44862-03 HOSE ASSEMBLY 122R2-04 112 IN L 4FJX90 6FJX 2
H05 44862-02 HOSE ASSEMBLY 122R2-04 70 IN L 4FJX90 6FJX 2
H20 44865-10 HYDRAULICS FITTING KIT - GM1 1
M01 446BC+MAN7 OPERATOR MANUAL UC4+ SPRAY HEIGHT CONTROL 1
M10 UC4+BC+GM1-INST MANUAL INSTALLATION UC4+ GREGSON, MAVERICK 120 1
V01 44963D VALVE BLOCK ASSEMBLY 2 STATION CC/LS PROP DT 4 BOLT 1
* For systems purchased BEFORE October 1, 2011, the roll sensor part numbers are 44641
and 44642.
