5 roll sensor installation – NORAC UC4+BC+GM1 User Manual
Page 16
14
4.5 R
OLL
S
ENSOR
I
NSTALLATION
Before installing the roll sensors you must
determine if your sprayer has a trapeze style or
center pivot style boom. For installation on a
trapeze style boom refer to Section 4.6. For
installation on a center pivot boom refer to
Section 4.7.
Figure 13: Trapeze Style Boom
Figure 14: Center Pivot Boom
Trapeze
Links
Center
Pivot
