INTRODUCTION

Thank you very much for purchasing the

MC-6, Digital Audio Format and

Sampling Rate Converter, from MUTEC!

General Function Description

The MC-6 is an extremely flexible, high-performance digital audio format
and sampling rate converter for AES3, AES3id and S/P-DIF. All digital audio
signals can be processed with sampling rates up to 192.0kHz, whereas
unidirectional and bidirectional conversion modes are available. Based on
latest FPGA designs, the MC-6 achieves levels of performance regarding
its signal quality, unique flexibility, clocking features and the 4 channel
sampling rate conversion engine (SRC), which are outstanding in today’s
industry!

Various operation modes enable the use of the MC-6 in many studio set-
ups. Incoming digital audio signals are generally converted to all three
audio formats simultaneously, with or without samplimng rate conversion.
The SRC engine can be locked to Word Clock, AES11 and any digital audio
input in both, unidirectional and bidirectional operation modes.

Furthermore, the MC-6 offers an internal, low-jitter clock basis with high
accuracy to which the SRCs can be locked to, if no external reference is
available. This enables to run the MC-6 in set-ups where no separate master
clock system is available. Furthermore, in this operation mode the MC-6‘s
Word Clock output supplies a low-jitter reference clock signal which is of
same high accuracy as the internal clock basis. This can be used e.g. as mas-
ter clock reference for the whole studio.

This all makes MC-6 for sure a unique and the most flexible digital audio
format converter in a 9.5“ case currently available in the market!

MC-6 Features

AES/EBU, AES/EBUid and S/P-DIF interfaces in one box.
Bidirectional format and sampling rate conversions
from 32.0 kHz to 192.0 kHz.
Converts standalone and bidirectionally with different sampling rates: X-SRC
Signal improvement through low-jitter clock recovery.
AES11, Grade 1, internal reference clock (<1ppm).
Word Clock output can be used as master clock reference.
Runs standalone without needing an external clock source.
4 channel SRC engine for bidirectional conversions.
Extremely flexible synchronization options.
Continuous signal supply in absence of the reference audio or clock signal.
Separate AES11 reference clock input.
Simultaneous conversions to all output formats.
Easy configurable.
User‘s settings will be stored after switching-off.
Rack space saving 1/2 19“ housing allowing for mounting two devices
in one rack unit.
Built-in international power supply.

MC-6 Applications

Interconnection of consumer and professional digital audio devices.
AES3, AES3id and S/P-DIF format and sampling rate conversions.
Integration of non-synchronizable devices into digital studio
environments.
Clock recovery and digital audio signal regeneration.
Realtime bidirectional signal transfer between send/returns of digital
mixing consoles and effect processors.
Unidirectional or bidirectional interconnection of computer-based sound
cards with professional digital audio equipment.
Usable within small studio set-ups up to broadcast installations.

7

Boxes which contain a triangle with
an exclamation mark inside should
be read carefully! These include

additional information which are of major
importance for the functional descriptions
in the text column.

!

The grey boxes contain supplementary
informationen for the corresponding
sections in the text columns. The content of
the individual box refers to the description
in the text column beside the box.

Register your MUTEC Product

for Warranty and Support!

We ask you to be so kind to register

your MUTEC product through our website
immediately after purchasing. This ensures
full warranty services over a period of two
years after purchasing the product. More-
over, for all registered products we offer to
our customers technical support. We also
will inform you about product updates and
new products which may of interest for you
(on voluntary base, of course).

Please regsiter your product at:

www.MUTEC-net.com

> SERVICES, > MUTEC Product Registration

!
