AP P E N D I X
AP P E N D I X
AP P E N D I X
> > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > >
> > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > > >
88
AES11 REFERENCE INPUT
Interface
1 x XLR female, transformer balanced, input impedance 110 Ω, 200 mV – 7.0 V
Format, Resolution
AES11 – 1997/2003, AES3 – 1992/2003, 16 – 24 bits
Lock Range
25.0kHz to 200.0kHz
AES3 AUDIO OUTPUT
Interface
1 x XLR male, transformer balanced, 3.5Vpp @ 110Ω, output impedance 110Ω, buffered
Format, Resolution
AES3 – 1992/2003, AES11 – 1997/2003, 24 bits
Transmitted Clock Rates
25.0kHz to 200.0kHz
AES3id AUDIO OUTPUT
Interface
1 x BNC, 1.0 V, unbalanced, input impedance 75 Ω
Format, Resolution
AES3id – 1995/2001, 24 bits
Transmitted Clock Rates
25.0kHz to 200.0kHz
S/P-DIF OPTICAL OUTPUT (OP)
Interface
1
x Toshiba Toslink
TM
, EIAJ RC-5720
Format, Resolution
IEC 60958, 24 bits
Transmitted Clock Rates
25.0kHz to 200.0kHz
S/P-DIF COAXIAL OUTPUT (CO)
Interface
1 x BNC, 0.5V, unbalanced, input impedance 75 Ω, buffered
Format, Resolution
IEC 60958, 24 bits
Transmitted Clock Rates
25.0kHz to 200.0 kHz
WORD CLOCK OUTPUT (WCLK)
Interface
1 x BNC, 3,5 V @ 22 Ω, unbalanced, buffered
Transmitted Clock Rates
25.0kHz to 200.0kHz
SIGNAL PROCESSING
Digital Audio Format
Conversion
AES3, AES3id, S/P-DIF (optical + coaxial) in every combination and direction
Sampling Rate Conversion
Lock range: 25.0kHz to 200.0kHz
Dynamic range: 144dB (A-weighted)
Resolution: 24Bits
THD+N: -140dB
Input/Output sampling ratio: 1:16 (upsampling), 16:1 (downsampling)
INTERNAL REFERENCE CLOCK SPECIFICATIONS
Oscillator Type
TCXO, temperature compensated crystal oscillator
Clock Accuracy (shipped)
< ± 1ppm
Clock Stability vs. Temperature
< ± 1ppm within -10°C to + 60°C
Operating Temperature
-10°C to + 60°C
Clock Jitter
< 10ps (RMS)
POWER SUPPLY
Type
Internal, switching power supply
Input Voltage
85V – 264V (automatic adjustment), 47Hz – 440Hz
Power Consumption
max. 10W
SYSTEM UNIT COVER
Cover Size / Material / Color
196 x 42 x 156mm without connectors (W x H x D), aluminium sheet 1mm, black
Front Panel Size / Material
198 x 44 x 2mm (W x H x D), aluminium
Weight
~ 670g
