Microtel D51T v.1.0 - Manual (Page 3)

MICROTEL D51T
1
TABLE OF CONTENTS
INTRODUCTION 2
CHAPTER 1 - DESCRIPTION OF THE D51T DIALER 4
CHAPTER 2 - INSTALLATION 8
Quick Start Procedure 11
CHAPTER 3 - OPERATION 13
Configuration 14
Basic System Information 14
Configuring Fault Inputs 16
Telephone Numbers 18
Operations 18
Alarm Acknowledgment 19
Checking System Status 19
Controlling the local output relay 20
CHAPTER 4 - MAINTENANCE/TROUBLESHOOTING 21
CHAPTER 5 - ADVANCED TOPICS 23
Advanced Configuration Options 23
APPENDICES 25
APPENDIX A: Technical Specifications 25
APPENDIX B: Glossary of Dialer Terminology 28
APPENDIX C: FCC Requirements 29
APPENDIX D: D51T Command Summary 30
APPENDIX E: Mechanical Dimensions 31
LIST OF ILLUSTRATIONS
Figure 1: Controls and Indicators................................................................................3
Figure 2: Power Supply Connection ...........................................................................8
Figure 3: I/O Terminal Connections ...........................................................................10
Figure 4: Mounting dimensions ..................................................................................30
