73M1822/73M1922 Modem CTL Application User Guide UG_1x22_056
12 Rev. 1.0
2.6 Exit Command
The exit command terminates the Modem CTL program. When issued, the user is prompted and asked
to confirm with a Y(es) or N(o). A “yes” terminates the program.
Syntax
1X22CTL:NN> exit
Where: NN Shows the current active channel ID.
The following is a log of the command to exit the Modem CTL program.
Figure 9: Exit Command Logging Session
2.7 Hook Switch Operation
The Modem CTL provides commands to manually control the hook switch operation of the FXO channel.
The FXO channel can be switched off hook or on hook.
2.7.1 Off-Hook Command
The offhook command brings the FXO channel off-hook.
Syntax
1X22CTL:NN> offhook (Current channel ID off-hook)
1X22CTL:NN> offhook XX (Channel ID XX off-hook)
Where: NN Shows the current active channel ID.
The following is a log of commands that bring the current channel ID and channel 4 off-hook.
Figure 10: Off-Hook Command Logging Session
Modem CTL:00> exit
Are you sure you want to quit? (Y or N)y
Good bye!
Modem CTL:00> offhook
Channel 0 is OFF-hook.
Modem CTL:00>
Modem CTL:00> offhook 4
Channel 4 is OFF-hook
Enter “Y” to confirm.
Take current channel (0) off-hook.
Take channel 4 off-hook.
