78M6610+PSU Evaluation Kit User Manual
Rev 2 19
4.5 78M6610+PSU 24-Pin Evaluation Board Bill of Materials
Table 5: 78M6610+PSU 24-Pin Evaluation Board Bill of Materials
Item Q Reference Part PCB Footprint Part Number Manufacturer RoHS-6
1 2 C1,C3 4.7uF 805 C2012Y5V1C475Z/0.85 TDK Yes
2 8 C2,C4,C5,C12,C17 0.1uF 603 C1608Y5V1H104Z TDK Yes
3 3 C7,C13,C15 1000pF 603 C1608X7R2A102K TDK Yes
4 2 C8,C11 27PF 603 CC0603JRNP09BN270 Yageo Yes
5 1 D1 Green 603 LG Q971-KN-1 OSRAM Yes
6 1 D2 Red 603 LTST-C190CKT Lite-On Yes
7 1 D3 Yellow 603 LTST-C190YKT Lite-On Yes
8 1 J2 5V Through hole PBC36SAAN Sullins Yes
9 1 J3 CON4 Through hole PBC36SAAN Samtec Yes
10 1 J4 UART Through hole PBC36SAAN Sullins Yes
11 1 J5 SIP100P3 Through hole PBC36SAAN Sullins Yes
12 1 J7 SPI port Through hole PBC36SAAN Sullins Yes
13 3 J13,J14,J16 CON2 Through hole PBC36SAAN Sullins Yes
14 1 RT1 THERMISTOR 603 NCP18XH103F03RB Murata Yes
15 1 R4 39 603 ERJ-3GEYJ390V Panasonic Yes
16 2 R7,R8 750 0.1% 603 ERA-3YEB751V Panasonic Yes
17 2 R11,R14 10K 603 ERJ-3EKF1002V Panasonic Yes
18 1 R15 360 603 ERJ-3EKF3600V Panasonic Yes
19 1 R17 150 603 ERJ-3EKF1500V Panasonic Yes
20 1 R12 15K 603 ERJ-3EKF1502V Panasonic Yes
21 5 R13,R16,R18,R20,R22 499 603 ERJ-3EKF4990V Panasonic Yes
22 4 R21,R23,R24 220 603 RC0603FR-07220RL Yageo Yes
23 1 R25 0 603 ERJ-3GEY0R00V Panasonic Yes
24 1 R26 3K 603 ERJ-3GEYJ302V Panasonic Yes
25 1 U1 MC78PC33 SOT 23-5 MC78PC33NTRG ON Semi Yes
26 1 U2 78M6610+PSU QFN24 78M6610+PSU/B00 Maxim Yes
27 5 U4,U5,U6,U8,U9 TCMT1107 SOP-4 TCMT1107 Vishay Yes
28 1 Y1 887-1143-1-ND 20MHz 4-SMD 8Z-20.000MAAJ-T TXC Yes
