73S12xxF USB-CCID Host GUI Users Guide UG_12xxF_037
6 Rev. 1.1
driver provides CCID compliant APDU level transfer of data and additionally addresses many of the
shortcomings of the Microsoft driver, including:
• Support for multiple reader slots.
• PIN pad support.
• LCD support.
• Vendor/device-specific string name support in the device manager.
• Support for mechanical features.
The Device Reader should be powered up and ready to run. The USB-CCID.exe program can be
invoked from the Windows taskbar Run button. Once the application is opened, the USB-CCID window
appears as shown in Figure 3.
Options Menu
Card Reader
Frame
Smart Card
Configuration
Frames
APDU
Command
Frame
EMV/ISO
Frame
LCD Frame
Keypad Frame
DFU Frame
Terminate Button Progress Indicator Transaction Window
Help Menu
Figure 3: USB CCID Host Application Window
