LABEC Shinva-45N User Manual
Page 20

18
It is located inside and at the back of the autoclave; you can find filter cover at the bottom of
the autoclave.
1. Lift up the autoclave
2. Remove filter cover
3. Remove filter screen
4. Clean filter screen
5. Refit filter screen and cover
7.3
Door interlock system
It is a safety device that prevents the door being opened when there is pressure in the chamber.
Its function as following:
1. Right close the door, the program can start.
2. When the door was locked but electronic lock and can not open, the program can start
3. When pressure balance between inside and outside and the electronic lock get back, the
door can open
Cover of filter
Fi l t er s cr een
