ENGLISH
Chapter 5: KGuard Web Client
64
DVR User’s Manual
5.5.2 Setting the Recording
Use the Record menu to remotely set the recording schedule and customize the recording settings, such as frame rate,
quality, and resolution.
1
On the Main Menu, click Remote Setting.
2
On the left panel, click Record.
3
Modify the necessary settings.
Item Description
Channel Select the channel that you want to configure.
Record Enable/Disable recording.
Pack
Duration Set the recording length for each video file (15/30/45/60 minutes). When the time
elapsed, the recording is saved to another file.
Record
Mode Select the record mode. Options are:
• Schedule: To record the video at a preset time. See “Setting the Recording
Schedule” below.
• Always: To record the video the whole day (24 hours).
Audio Enable/Disable audio recording.
Frame Rate Select the frame rate. Options are:
• Fixed: To apply the fixed frame rate based on the selected resolution.
• Manual: To set the frame rate manually. If this option is selected, the Frame Rate
field appears. Enter desired frame rate value between 1 to 30.
Note:
The maximum frame rate varies depending on the selected resolution.
Quality Select the recording quality (Best/Fine/Normal).
Resolution Select the recording resolution (CIF/HD1/D1).
4
To save the settings, click Apply at the bottom of the screen.
« TIP »
• To apply the same recording settings to other channels, click Copy To at the bottom of the screen. See
”Copying Settings To Other Channels” on page 60.
• To revert to default settings, click Default at the bottom of the screen.
• To cancel any modifications and retain the existing settings, click Refresh at the bottom of the screen.
Setting the Recording Schedule
To automatically record a channel at a specified time, do the following:
1
On the Main Menu, click Remote Setting.
2
On the left panel, click Record.
