10 Preload, Deadload and Overload settings
Kern model Deadload** (kg)
**= already applied preload
Center Overload
Protection circa (kg) Corner Overload
Protection circa (kg) Loadcell
Capacity (kg)
KFP 600V40SM 90 NA N/A 500kg
KFP 1500V40SM 90 NA N/A 1000kg
KFP 1500V40M 120 NA N/A 1000kg
KFP 3000V40M 120 NA N/A 1500kg
Platform type Platform dimension
(mm) Loadcell TC Class Max E
max
E
min
Y n Dead-load T
min
T
max
Cable-
Type No. Preload -1 -4 -3 (kg)
-5 -6
length
(kg) (kg) (g) (m)
KFP
600V40SM
1000x1000x80
CZL-8C-
0.5T
D09-03.19 C3 300 500 0 10000 3000 300 -10 40 5
KFP
1500V40SM
1000x1000x80 SQB TC6911 C3 750 1000 0 10000 3000 750 -10 40 5
KFP
1500V40M
1500x1250x90 SQB TC6911 C3 750 1000 0 10000 3000 750 -10 40 5
KFP
3000V40M
1500x1250x80 SQB TC6911 C3 1500 1500 0 10000 3000 1500 -10 40 5
