9 Service documentation
• This chapter is only intended for a balance specialist!
• The weighing bridges are carried out in DMS sensor technology, at
every corner a DMS weighing cell is installed.
• The analogue-digital transformation occurs in the display unit. Also all
the balance and country-specific data are stored there.
9.1 Overview, setting regulation, tolerances
Testing and setting regulations:
Capacity 1500 kg
Readability 500 g
Min 10 kg
Max 1500 kg
1/3 corner load 500 kg
Tolerance 500 g
Verification data and tolerances as per OIML
-1
-0,75
-0,5
-0,25
0
0,25
0,5
0,75
1
0 500 1000 1500
[kg]
[g]
1500 kg
13 KFP V40-IA-e-1412
