GAB-N-BA-e-1315 37
12.1.3 Explanation of the data transfer
Example:
Header1 , Header2 , -/space W1 W2 W3 W4 W5 W6 W7 , unit terminator
Header 1 2 byte, St or US, ST=weighing value stable, US=weighing value
instable
Header 2 2 byte, G or N, G=gross weight, N= net weight
space Blank
W1-W7 Weight value with decimal position
Unit 2 byte, kg or lb
Terminator (CR=Carriage return)
(LF= Line Feed)
12.2 Remote control instructions
The remote control commands are sent from the remote control unit to the balance
as ASCII code. After the balance having received the s/w/t commands, it will send the
following data.
Take into account that the following remote control commands must be sent without a
subsequent CR LF.
T: tare Taring
Z: zero Zeroing
SI: stable status Output of instable weighing values (US) or stable weighing values
(ST)
ST stable status or
not
Output of stable weighing values (Y) or instable weighing values
(N)
