Cardo G4 User Manual

Page 19

gli

Your 4-Way Conference Intercom Pairing is now complete and ready

to use.

NOTE: If the Pairing process is not completed within two minutes the G4s

will return to Standby mode.

Making 4-Way Intercom calls
Once you have successfully paired the four G4s as described above,

and all units are in standby mode, proceed as follows to start a 4-way

Conference Intercom call:

a. Passenger 2 should press Button “B” to initiate a call with

Passenger 4. Wait until audio is heard on both G4s and proceed

to the next step.

b. Driver 1 should press Button “A” to initiate a call with Passenger 2.
c. Driver 3 should press Button “A” to initiate a call with Passenger 4.

Now the 4-way intercom conference mode is established.

NOTE: If one of the G4s should disconnect or drop off from the 4-way call and

fails to reconnect, repeat the three steps above in that precise order.

9.11 USING THE G4 FOR INTERCOM WITH OTHER

SCALA RIDER MODELS
9.11a. TWO-WAY INTERCOM WITH SCALA RIDER Q2/Q2

pro

To use your G4 with a Q2 unit, we recommend that you also refer to

your Q2 manual.
1. If either device is turned OFF, turn it ON by pressing and holding

either the Mobile Button for the G4 unit or the CTRL Button for the

Q2 until the Blue Lights flash three times.

2. Make sure that both devices are now flashing slowly in Blue.
3. On the G4, select an available CHANNEL to pair the Q2 (CHANNEL

“A” or CHANNEL “B”).

NOTE: Selecting a CHANNEL that is already in use will replace the paired

headset on that CHANNEL with the newly paired headset.

4. On the G4, press and hold the assigned CHANNEL BUTTON (“A” or

“B”) for at least six seconds until the G4’s BLUE or RED Light begins

flashing rapidly, indicating it is in Intercom Pairing mode. (See Table

in 9.10).

5. On the Q2, simultaneously press and hold the CTRL and MC

Buttons until the RED Light begins flashing rapidly, indicating it is in

Intercom Pairing mode (see Q2 manual).

6. Within a few seconds, both units will show a solid light for two

seconds, indicating that they are now paired, connected and ready

for use.

NOTES:

• If the Pairing process is not completed within two minutes the units will

return to Standby mode.

• Voice Connect Intercom can only be initiated from the G4/Q2

pro

However, you can always initiate the Intercom manually also from a Q2

unit by pressing the button.

scala rider
