Initiate Intercom calls

There are two ways to start an Intercom call with your paired G4s while the

G4 is in Standby mode:

VOICE CONNECT:
Start talking loudly
Once you start talking loudly, an Intercom

call will be established with both paired G4s,

CHANNEL “A” and CHANNEL “B” (if both are

available).

CHANNEL BUTTON

CONNECT:
Single tap the CHANNEL

“A” or “B” Button to add or

remove the desired channel

from an Intercom call.

9.10c. FOUR-WAY INTERCOM
When connected to three other G4 units, your G4 can also

participate in a 4-way Conference Intercom Call (full duplex) as

explained below.
Please note that the 4-way conference operates in a linear manner,

whereby the two passengers serve as the connecting links for the

entire group. Therefore, if one of the Passengers disconnects, the

4-way conference mode will be interrupted until that passenger is

reconnected.
4-Way Intercom between up to two couples on two motorcycles
two drivers (1 and 3) and two passengers (2 and 4)

In this configuration the two passengers (numbered 2 and 4) are each

using two Bluetooth connections:

Passenger 2 is paired to Driver 1 and to Passenger 4
Passenger 4 is paired to Driver 3 and to Passenger 2

IMPORTANT: Since both Passengers each use two Bluetooth connections

during the conference mode, they will both be disconnected from their

mobile phones until the conference mode is terminated. Upon termination,

both Passengers will automatically re-connect to their mobile phones. Both

Drivers 1 and 3 remain connected to their mobile phones or GPS devices

during the 4-way intercom call.

PAIRING FOUR SCALA RIDER G4s
To converse in the 4-Way intercom conference mode, the four G4s

must be paired as shown in the biker illustration above. All four units

should initially be turned off.
Step One: Pair Driver 1 to Passenger 2 via Channel “A” as follows

a. Turn both G4s ON by pressing and holding the Mobile Buttons

until the Blue Light flashes three times.

b. Both G4s should now be flashing slowly in Blue.
c. Press and hold CHANNEL (“A”) BUTTON on both G4s for at least

six seconds until the G4’s BLUE or RED Light begins flashing

rapidly, indicating that they have entered the Intercom Pairing

mode. (See Table in section 9.10)

d. Release the buttons and wait until both G4s display a solid light

for two seconds, indicating that the two G4s are now paired for

Intercom connection. (This may take up to two minutes).

Step Two: Pair Driver 3 to Passenger 4 via Channel “A”
Repeat the above pairing procedure between Driver 3 and Passenger 4.
Step Three: Pair Passenger 2 to Passenger 4 via Channel “B”
Repeat the above pairing procedure between Passenger 2 and

Passenger 4 using the Channel “B” button. (instead of Channel “A”

button as described in point “c” of Step One above).
