9.10a. TWO-WAY INTERCOM
PAIRING OPTIONS BETWEEN TWO PARTICIPANTS
Using two G4s
1. If either G4 is turned OFF, turn it ON by pressing and holding the

Mobile Button until the Blue Light flashes three times.

2. Make sure that both G4s are now flashing slowly in Blue.
3. Choose an available CHANNEL you wish to use to pair the G4

(CHANNEL “A” or CHANNEL “B”).

NOTE: Selecting a CHANNEL that is already in use will override the paired

G4 on that CHANNEL with the newly paired G4.

4. On the G4, press and hold the chosen CHANNEL BUTTON (“A” or

“B”) for at least six seconds until the G4’s BLUE or RED Light begins

flashing rapidly, indicating it is in Intercom Pairing mode. (See Table

in 9.10).

5. Repeat Step 3-4 for the second G4.
6. Within a few seconds, both G4s will show a solid light for two

seconds, indicating that the two G4s are now paired, connected

and ready for use.

NOTE: If the Pairing process is not completed within two minutes the G4

will return to Standby mode.

Initiate Intercom calls

There are two ways to start an Intercom call with your paired G4 while the

G4 is in Standby mode:
VOICE CONNECT:
Start talking loudly
Once you start talking loudly, an Intercom call

will be established with the other paired G4.
The Intercom call will stay on until all

participants remain silent for 30 seconds.

CHANNEL BUTTON

CONNECT:
Tap the chosen CHANNEL

Button once to add or

remove the other G4 from

an Intercom call.

9.10b. THREE-WAY INTERCOM
The G4 offers three-way intercom conference connectivity as follows:

First G4

Rider “A”

Third G4

Rider “C”

Second G4

Rider “B”

In this configuration Rider “B” is paired to Rider “A” and to Rider “C”.

IMPORTANT: Since Rider “B” uses two Bluetooth connections during the

conference mode, Rider “B” will be disconnected from the mobile phone

or GPS device until the conference mode is terminated. Upon termination,

Rider “B” will automatically re-connect to his mobile phone or GPS. Rider

“A” and “C” remain connected to their mobile phones or GPS devices

during the 3-way intercom call.

Set-up and configuration three-way intercom connectivity
PAIRING OPTIONS BETWEEN THREE PARTICIPANTS (between G4

models only)
Pairing three G4s is achieved by simply repeating the procedure in

the above section 9.10a with a third paired G4. To pair your G4 with

another two G4s:

1. Pair your G4 with the second G4 as described in section 9.10a

(Using CHANNEL “A”).

2. Pair your G4 with the third G4 as described in section 9.10a

(Using CHANNEL “B”).

Use C

hann

el “B

”

Use Cha

nnel “A”
