Jaypro Sports BBC-UBKIT - Manual (Page 7)

© 2010 Jaypro Sports Equipment BBC-700B-M 02-08-2012
7 of 24
ITEMS AND COUNTS
PACKAGE 1 TW-1200X-3C
(1) TW-1200X-3C WINCH
(1) KS-13 KEY SWICH
PACKAGE 2 BBC-700DT
(7) DRIVEPIPE-B 2-3/8" OD GALV TUBES 135.75"
PACKAGE 3 BBC-700DMK
(6) HS292 3/8-16 X 3" HX HD BOLT
(6) HN265 3/8-16 NYLON LOCK NUT
(18) HM6134 1/2-13 CHANNEL NUT
(18) HM6135 1-5/8 SQ STRUT WASHER W/ 9/16" HOLE
(26) HN5038 1/2-13 FLANGE NUT
(2) HS5040 1/2-13 X 4" HX HD BOLT
(2) HN2951 1/2-13 NYLON LOCK NUT
(4) HW2044 1/2 FLAT WASHER
(14) HN5016 1/2-13 X 1-3/4" COUPLING NUT
(14) HW1245 1/2 SPLIT RING LOCK WASHER
(14) HN269 1/2-13 HX NUT
(28) HS5091 5/16-18 X 1/2" SET SCREW
(4) SR5187 1/2-13 X 12" THREAD ROD
(14) SR5276 1/2-13 X 18" THREAD ROD
(7) DPC-2 DRIVE PIPE CARRIER ASSEMBLY
(14) CG-6 6" CABLE GUIDE FITTING
PACKAGE 4 BBC-700CK
(1) NW0048 3/4" X 25 YDS BLACK VELCRO 'ONE WRAP
(35) HM403 1/8" WIRE ROPE CABLE CLAMP
(21) HM6169 1/8" WIRE ROPE CABLE THIMBLE
(21) HB5048 3/8-16 X 5" EYE BOLT
(42) HW2050 3/8 FLAT WASHER
(21) HN265 3/8-16 NYLON LOCK NUT
(124) HS5144 #10 X 1" RND WASHER HD PHILLIPS SCREW
(7) RC5017-14 1/8" AIRCRAFT CABLE 7X19 GALVANIZED 14'
(7) RC5017-40 1/8" AIRCRAFT CABLE 7X19 GALVANIZED 40'
(4) BBC-EL CAGE ELBOW FITTING
(18) BBC-T CAGE T FITTING
PACKAGE 5 & 6 BBC-700CP & BBC-700CP-1
(2) AP5008-20 1.90 OD ALUM TUBE 20"
(9) BBC-PIPE-A 1.90 OD ALUM TUBE 144" W/ 3 HOLES
(4) AP5008-288 1.90 OD ALUM TUBE 288"
(2) AP5008-264 1.90 OD ALUM TUBE 264"
*Hardware in PACKAGE 3 will vary for BBC-RIGKIT (See BBC-RIGKIT support drawing package for detail parts list.)
