Ex Series Ex3200
REF
NO. PART NUMBER DESCRIPTION QTY
1 CY-129129-77010 STARTER ASSY 1
2 CY-X0283060061 ROLLER 5
3 CY-129129-77460 SCREW 2
4 CY-X9490561370 NUT 1
5 CY-X9491200240 BALL 1
6 CY-129129-77210 YOKE ASSY 1
7 CY-129129-77220 ARMATURE ASSY 1
8 CY-129129-77230 BEARING 1
9 CY-129129-77240 BEARING 1
10 CY-129129-77250 STARTER ASSY 1
11 CY-X0280210230 NUT 1
12 CY-X0283270140 RETAINER 1
13 CY-X9491703371 SPRING, COIL 1
14 CY-129129-77390 CLUTCH ASSY, STARTER 1
17 CY-129129-77400 SHAFT 1
18 CY-129129-77410 SPRING, COIL 1
19 CY-129129-77420 PINION 1
20 CY-129129-77430 RING 1
21 CY-129129-77260 RETAINER 1
22 CY-129129-77270 PINION 1
23 CY-129129-77280 HOUSING 1
24 CY-129129-77290 FRAME 1
25 CY-129129-77300 HOLDER ASSY 1
26 CY-X9491730461 SPRING 4
27 CY-129129-77310 SWITCH ASSY 1
28 CY-129129-77320 BOLT 2
29 CY-129129-77330 BOLT 2
30 CY-129129-77340 SPRING 1
31 CY-129129-77350 O-RING 2
32 CY-129129-77362 COVER 1
34 CY-129129-77380 CAP 1
35 CY-129155-77060 BOLT, STARTER 1
36 CY-26116-120202 BOLT M12X 20 PLATED 1
FIG. 15. STARTER
23
