Ex Series
Ex3200
REF
NO.
PART NUMBER
DESCRIPTION
QTY
REF
NO.
PART NUMBER
DESCRIPTION
QTY
1
CY-194990-22130
NUT W/WASHER 6
1
28
CY-194250-51650
CLAMP 66
4
2
CY-194990-22140
NUT W/WASHER 8 - S/N
F000155 & BELOW
1
29
CY-194680-51670
BAND
2
2
CY-194990-22050
NUT W/WASHER 8 - S/N
F000156 & ABOVE
1
30
CY-194680-51670
BAND
1
3
CY-1A8160-51100
WIRING HARNESS A
CMP
1
31
CY-1A7260-51710
GROMMET, CABLE
1
4
CY-1A7500-51130
DIODE, 3.0A
1
32
CY-1A7260-52510
STAY, FUSE BOX
1
5
CY-1A8160-51130
DIODE, 3.0AX2
1
33
CY-124550-77030
COVER, TERMINAL
1
6
CY-1A7500-51160
CLIP, HARNESS
2
34
CY-198291-77870
COVER, HOSE
PROTECTOR
2
7
CY-194275-51160
COUPLER
1
35
CY-198291-77870
COVER, HOSE
PROTECTOR
1
8
CY-194275-51170
PLUG
1
36
CY-198291-77870
COVER, HOSE
PROTECTOR
1
9
CY-198535-52110
FUSE
4
37
CY-198291-77870
COVER, HOSE
PROTECTOR
1
10
CY-198535-52120
FUSE 10A
4
38
CY-1E6102-83230
CLAMP, BATTERY
CABLE
1
11
CY-198535-52130
FUSE 15A
2
39
CY-194440-51620
CLAMP, WIRE
HARNESS
1
12
CY-1A7260-52410
COVER, FUSE BOX
1
40
CY-26106-060122
BOLT M 6X 12 PLATED
2
13
CY-1A8160-65440
LABEL, FUSE
1
41
CY-26106-060162
BOLT M 6X 16 PLATED
4
14
CY-1A7330-51130
HARNESS C ASSY.
2
42
CY-26106-080122
BOLT M 8X 12 PLATED
4
15
CY-1A8160-51180
WIRING HARNESS,
START
1
43
CY-1C6560-06300
BOLT M8X16, EARTH
1
16
CY-198153-51700
FUSE, 80A SLOW BLOW
2
44
CY-26106-080122
BOLT M 8X 12 PLATED
1
17
CY-1A8160-51200
WIRING HARNESS B
CMP
1
45
CY-26106-080122
BOLT M 8X 12 PLATED
1
18
CY-1A7500-51130
DIODE, 3.0A
1
46
CY-26106-080122
BOLT M 8X 12 PLATED
1
19
CY-198220-51170
WIRE
1
47
CY-26106-080122
BOLT M 8X 12 PLATED
2
20
CY-194170-51210
GROMMET, 25
2
48
CY-26106-080302
BOLT M 8X 30 PLATED
1
21
CY-198220-51250
CLAMP - S/N F000155 &
BELOW
1
49
CY-29622-140001
BAND 140
1
21
CY-194440-51620
CLAMP - S/N F000156 &
ABOVE
1
50
CY-29622-140001
BAND 140
2
22
CY-1A8160-51310
WIRING HARNESS,
1
51
CY-29622-140001
BAND 140
2
23
CY-198253-51410
CABLE
1
52
CY-29622-140001
BAND 140
4
24
CY-1A8160-51420
CABLE, BATTERY,NEG
1
53
CY-29622-250001
BAND RF 250
1
25
CY-194440-51620
CLAMP, WIRE HARNESS
2
54
CY-29622-250001
BAND RF 250
1
26
CY-194440-51620
CLAMP, WIRE HARNESS
4
55
CY-198291-77870
COVER, HOSE
PROTECTOR
1
27
CY-194680-51670
BAND
1
56
CY-194990-22140
NUT W/WASHER 8
1
FIG. 82. WIRE HARNESS
