Ex Series Ex3200
REF
NO. PART NUMBER DESCRIPTION QTY
1 CY-1A7260-60640 URETHANE, A COVER 2
2 CY-1A7260-60670 URETHANE, B COVER 2
3 CY-1A7260-60780 BRACKET, L 1
4 CY-1A7260-60790 BRACKET, R 1
5 CY-1A7260-60900 URETHANE, C COVER 2
6 CY-1A7260-60920 BRACKET, L.H. COVER 1
7 CY-1A7260-60930 BRACKET, R.H. COVER 1
8 CY-1A8160-61000 COVER (M ASSY SIDE L) 1
9 CY-198129-05190 NUT, PUSH 6 12
10 CY-1A7260610601 NET, L SIDE COVER 1
11 CY-1A8160-61010 COVER (M ASSY,SIDE R) 1
12 CY-198129-05190 NUT, PUSH 6 12
13 CY-1A7260610701 NET, R SIDE COVER 1
14 CY-198220-61351 LOCK COMP.,CAM 4
15 CY-1A8160-61400 STAY, SIDE COVER 4
16 CY-198220-61800 RUBBER, CUSHION 4
17 CY-26106-060122 BOLT M 6X 12 PLATED 4
18 CY-26106-060122 BOLT M 6X 12 PLATED 4
19 CY-26106-080122 BOLT M 8X 12 PLATED 8
141
FIG. 93. SIDE COVER
Copyright 2007 Cub Cadet Yanmar LLC
