Ex Series
Ex3200
REF
NO.
PART NUMBER
DESCRIPTION
QTY
REF
NO.
PART NUMBER
DESCRIPTION
QTY
1
CY-729269-51300
INJECTION PUMP ASSY
1
94
CY-158601-51790
PLUG
1
7
CY-119802-51090
KEY, WOODRUFF 4X16
1
95
CY-22190-120002
SEAL WASHER 12
1
32
CY-158600-51270
STOPPER
1
96
CY-22190-180002
SEAL WASHER 18
1
33
CY-158563-51281
O-RING
1
97
CY-23887-120002
PLUG M12, HEX.
1
34
CY-158563-51281
O-RING
1
99
CY-158553-51770
BOLT
4
35
CY-129008-51300
VALVE ASSY, DELIVERY
3
100
CY-158552-52310
O-RING
1
43
CY-158563-51330
SPRING
3
101
CY-158552-52400
O-RING 4E S42
1
44
CY-129008-51340
HOLDER, DELIVERY
3
102
CY-22190-120002
SEAL WASHER 12
2
51
CY-158601-51550
PLUG
1
103
CY-22190-180002
SEAL WASHER 18
2
52
CY-119802-51560
BARREL PLUG
1
104
CY-22217-140000
SPRING WASHER 14
1
53
CY-158552-51570
GASKET
3
105
CY-22312-050140
PARALLEL PIN 5X14
2
54
CY-158552-51570
GASKET
1
106
CY-22351-050010
SPRING PIN 5X10
2
55
CY-158557-51570
PLUG
1
108
CY-24311-000070
O-RING 1A P-7.0
1
56
CY-158601-51570
PLUG, WATER PUMP
1
109
CY-24356-010180
O-RING
1
57
CY-158552-51580
LIFTER
1
110
CY-24356-010200
PACKING, 1020
1
58
CY-119802-51590
TIMER SET
1
111
CY-26106-060102
BOLT 6X 10 PLATED
1
59
CY-119802-51600
TIMER CMP
1
115
CY-26450-080452
BOLT M 8X 45
4
62
CY-158553-51670
O-RING, 1011
1
116
CY-26776-140002
LOCK NUT M14 PLATED
1
63
CY-119802-51680
BACKUP RING
1
119
CY-158553-51551
JOINT, COOLING WATER
1
64
CY-119802-51690
O RING
1
120
CY-158601-51650
JOINT
1
65
CY-24356-010200
PACKING, 1020
1
121
CY-158552-51670
JOINT
1
66
CY-24372-000150
RING, BACKUP T2 P 15
1
123
CY-158552-52100
PUMP ASSY, FEED
1
67
CY-158552-51600
PACKING, HEAD
1
124
CY-158552-52500
O-RING, FEED P INNER
1
68
CY-158553-51630
SPRING, TIMER
1
125
CY-129916-59020
JOINT 12, PIPE
1
70
CY-158553-51640
ELEMENT, THERMO
1
127
CY-22190-120002
SEAL WASHER 12
2
71
CY-158553-51660
O-RING,P14
1
128
CY-23857-060000
JOINT BOLT 6,PIPE
1
72
CY-158553-51680
PACKING, TIMER
1
129
CY-119802-51250
BRACKET, PUMP
1
92
CY-158601-51770
PISTON
1
130
CY-26106-080162
BOLT M 8X 16 PLATED
1
93
CY-158552-51781
DAMPER ASSY
1
131
CY-26106-080202
BOLT M 8X 20 PLATED
1
19
FIG. 12. FUEL INJECTION PUMP
