SAVE THESE INSTRUCTIONS
Page 8
English
PARTS REFERENCE (continued)
Before assembling your product, please take a few minutes to check the contents and
become familiar with all the parts.
PARTS
REFERENCE
When ordering parts, be sure to quote the model number and part numbers.
REF. NO.
DESCRIPTION QTY.
SPARE
PART NO. SMALL AGP LARGE AGP COMMON PARTS
1 AIR RELEASE VALVE/SEDIMENT RELEASE VALVE 2 10460
2 VALVE O-RING 2 10264
3 THREADED FILTER HOUSING COLLAR 1 10749
4 FILTER HOUSING COVER 1 10750
5 FILTER HOUSING O-RING 1 10325
6 FILTER CARTRIDGE (59900) 1
7 AIR RELEASE VALVE B (WITH O-RING) 1 10725
8 PUMP HOSE WITH NUTS 2 10493
9 WATER TRANSFER HOSE (WITH COLLAR AND 2 HOSE CLAMPS) 1 11583
10 SCREW 2 11519
11 FLOW SENSOR 1 11460
12 ELECTROLYTIC CELL NUT 1 11582
13 ELECTROLYTIC CELL (O-RING C INCLUDED) 1 11578
14 COPPER ELECTRODE 1 11579
15 L-SHAPE O-RING 1 11228
16 O-RING C 1 10717
17 ANGLE JOINT (O-RING D INCLUDED) 1 11584
18 O-RING A 1 11587
19 PLUNGER VALVE (HOSE O-RING & STEP WASHER INCLUDED) 2 10747E
20 HOSE O-RING 10262
21 STEP WASHER 10745
22 STRAINER NUT 2 10256
23 FLAT STRAINER RUBBER WASHER 2 10255
24 THREADED STRAINER CONNECTOR 2 11235
25 ADJUSTABLE POOL INLET NOZZLE 1 11074
26 ADAPTOR B (OPTIONAL) 2 10722
27 STRAINER CONNECTOR (OPTIONAL) 2 11070
28 POOL INLET NOZZLE (OPTIONAL) 1 11071
29 STRAINER GRID (OPTIONAL) 1 11072
30 CELL COVER 1 11131
31 COPPER ELECTRODE NUT 1 11580
32 TITANIUM ELECTRODE 1 11581
33 CHLORINE TEST STRIPS 1 19635
34 COPPER TEST STRIPS 1 11254
35 VACUUM RELEASE VALVE 2 11437
36 VACUUM RELEASE VALVE CAP 2 11576
37 TITANIUM ELECTRODE O-RING 1 11585
38 COPPER ELECTRODE O-RING 1 11586
39 CONTROL STATION 1 11590
40 COLLAR NUT 1 11604
