Micro Door/Window Sensor Installation Instructions
Mounting the Sensor
Mount the sensor using the supplied mounting
screws for permanent mounting for all UL
installations. For non-UL installations, using the
supplied double-sided tape is optional. Note:
The gap between the sensor and magnet
should not exceed a maxim
um of 3/8”.
Mounting Screws (UL Installations)
1.
Remove the sensor base from the sensor.
2.
Place the sensor base in desired location
and mount the base with the supplied
screws. Attach the sensor to the base.
3.
Mount the magnet into the desired location
using the supplied screw and lock washer,
making sure the alignment mark lines up
with the sensor’s.
Double-Sided Tape (optional for non-UL
installations)
1.
Before applying double-sided tape, ensure
that the desired location is a smooth, clean
and dry surface.
Note: When applying the double-sided
tape, evenly apply pressure to ensure a
good surface contact.
2.
Apply double-sided tape to the bottom of
the sensor and the magnet. Mount the
sensor and magnet at the desired
locations, ensuring the alignment marks
line up with each other.
For Additional Tamper Security
1.
Punch out the seal covering the screw hole
on the sensor cover end.
2.
With the sensor base attached to the
sensor cover, insert the smallest screw
supplied, securing the sensor base to the
sensor cover.
Specifications
Model no.
TX-1012-01-1 (white)
TX-1012-01-3 (brown)
RF frequency
319.5 MHz
Compatibility
Interlogix Learn Mode Panels
and Receivers
– Concord,
NetworX and Simon Series
Battery type
3-VDC, lithium coin-cell battery
(Varta or Panasonic, Model
CR2032)
UL Approved Battery
Varta CR2032
Panasonic CR2032
Operating
temperature range
32 to 120°F (0 to 49°C)
Storage temperature
range
-30 to 140°F (-34 to 60°C)
Relative humidity
95% non-condensing
Dimensions
(L x W x D)
1.9 x 1.0 x 0.50 in. (4.7 x 2.5 x
1.3 cm)
Regulatory information
Manufacturer
UTC Fire & Security Americas
Corporation, Inc.
1275 Red Fox Rd., Arden Hills, MN
55112-6943, USA
FCC
compliance
This device complies with part 15 of
the FCC Rules. Operation is subject to
the following two conditions: (1) This
device may not cause harmful
interference, and (2) this device must
accept any interference received,
including interference that may cause
undesired operation.
FCC ID: B4Z-983-UDWS
IC: 1175C-983UDWS
This Class B digital apparatus
complies with Canadian ICES-003.
Cet appareil numérique de la classe B
est conforme à la norme NMB-003 du
Canada.
UL
ANSI/UL 634 Standard for Connectors
and Switches for Use with Burglar-
Alarm Systems
UL 1023
– Household Burglar-Alarm
System Units.
ULC
C634-M1986 - Connectors and
Switches for Use with Burglar-Alarm
Systems
CAN/ULC-C1023-1974. Preliminary
Standard for Household Burglar Alarm
System Units.
Contact Information
For contact information, s
or call +1 855 286 8889.
© 2013 United Technologies Corporation.
Interlogix is part of UTC Building and Industrial
Systems, a unit of United Technologies
Corporation. All rights reserved.
