16 IFS MC250-4T/XXX Series User Manual
Temperature
Operating: -40~75 Degree C
Storage: -40~85 Degree C
Humidity Operating
Operating: 5% to 90%, Storage: 5% to 90% (Non-
condensing)
Regulation Compliance FCC Part 15 Class A, CE
Model M250-4T/2S
Hardware Specification
Ports 4 x 10/100Base-TX, Auto-negotiation, Auto-MDI/MDI-X
Copper
Cable
10Base-T : 2-pair UTP Cat. 3, 4, 5 cable (100meters,
max.)
100Base-TX : 2-pair UTP Cat. 5, 5e, 6 cable
(100meters, max.)
Port 2 x 100Base-FX
Cable
Mode
Multi-Mode:
50/125
μm fiber
62.5/125
μm fiber
Single-Mode:
9/125
μm fiber
Fiber
Optical
Distance
Depend on
SFP Module
Dimensions (W x D x H) 135mm x 97mm x 32mm
Weight 442g
Power Requirement
12~48V DC,
Redundant power with polarity reverse protection
function
Power Consumption /
Dissipation
16 Watts / 54BTU
Installation DIN Rail Kit and Wall Mount Ear
Switch Specification
Switch Processing
Scheme
Store-and-Forward
Address Table 2K entries
Buffer 1Mbit
Flow Control
Back pressure for Half duplex,
IEEE 802.3x Pause Frame for Full duplex
Switch Fabric 1.2Gbps
Throughput
(Packet Per Second)
0.89Mpps @ 64Bytes
Standards Conformance
