IFS MC250-4T/XXX Series User Manual 15
Specifications
Model MC250-4T/1FM MC250-4T/1FS
Hardware Specification
Ports 4 x 10/100Base-TX, Auto-negotiation, Auto-MDI/MDI-X
Copper
Cable
10Base-T : 2-pair UTP Cat. 3, 4, 5 cable (100meters,
max.)
100Base-TX : 2-pair UTP Cat. 5, 5e, 6 cable
(100meters, max.)
Port 1 x 100Base-FX
Cable
50/125
μm fiber
62.5/125
μm fiber
9/125
μm fiber
Mode Multi-mode Single-mode
Fiber
Optical
Distance 2km 15km
Dimensions (W x D x H) 135mm x 97mm x 32mm
Weight 436g
Power Requirement
12~48V DC,
Redundant power with polarity reverse protection
function
Power Consumption /
Dissipation
13.7 Watts / 46BTU
Installation DIN Rail Kit and Wall Mount Ear
Switch Specification
Switch Processing
Scheme
Store-and-Forward
Address Table 2K entries
Buffer 1Mbit
Flow Control
Back pressure for Half duplex,
IEEE 802.3x Pause Frame for Full duplex
Switch Fabric 1Gbps
Throughput
(Packet Per Second)
0.74Mpps @ 64Bytes
Standards Conformance
Standards Compliance
IEEE 802.3 Ethernet, 10Base-T
IEEE 802.3u Fast Ethernet, 100Base-TX, 100Base-FX
IEEE 802.3x Full-duplex Flow control
Stability testing
IEC60068-2-32(Free Fall)
IEC60068-2-27(Shock)
IEC60068-2-6(Vibration)
