600-1053-4 Concord 4 CDMA Module Installation Sheet
Power up
You will need to power up the module and panel to start
communication between them.
To power up:
1. Verify that all wiring between the panel and module is
correct.
2. Connect the backup battery and restore AC power to the
panel.
Note: Whenever any module is added or changed, you
must remove panel power and reapply it for the panel and
module to communicate successfully.
3. Enter installer program mode and turn off the Access
Code Lock feature (in the Security menu).
This must be set to off for the system to communicate with
Alarm.com. The module PWR LED should turn on. After a
few seconds, the module BUS and AUTO LEDs should
flash to indicate successful communication with the panel.
4. Verify that cellular status LED L1 is not flashing any errors
and that LED L4 is flashing at least a level of two.
Otherwise, relocate the module. If LED L1 and LED L4 are
not flashing at all, and LED L2 and LED L3 are flashing
together, the module is in power save mode and the
battery needs to be changed.
5. Do an installer cellular manual phone test (at system
touchpad, enter 8, installer code, 3). Disarm the panel by
entering 1
the phone test.
Before doing the manual phone test, the bottom red status
LED should be on and the yellow status LED should be
flashing. The yellow LED will stay on solid once the
manual phone test is completed.
Note: Do not press any system touchpad buttons during
the 5 to 8 minutes, or the time will not set. During this time,
the keypad will go in and out of programming mode and
will beep several times.
Status LEDs
The status LEDs located on the left side of the module indicate
the current signal and the status of the wireless gateway
module. The bottom red LED indicates if the module is in range
and if it is registered. The yellow and green LEDs indicate the
message status. The top LED is not used.
Red LED
•
On when the module is in range and registered with the
network.
•
Off when the module is out of range and not registered
with the network.
•
Blinks when the module is registered with the network, but
out of range.
Yellow LED
•
On after the first message has been sent by the module
and received by Alarm.com.
•
Off until a message has been sent by the module.
•
Blinks when the first message is being sent by the module.
Green LED
•
Off as soon as Alarm.com receives the message from the
module (off most of the time).
•
Blinks when the message is being sent by the module.
Table 3 below describes status LED condition patterns.
Table 3: Status LED condition patterns
Number Red
LED
Yellow
LED
Green
LED
Module condition
1
Off
Off
Off
Not powered up/not working.
2
On
Off
Off
In range, first message not
sent, not currently sending
message.
3
On
On
Off
In range, first message sent,
not currently sending message.
4
On
On
Blinks
In range, first message sent,
currently sending message.
5
On
Blinks
Blinks
In range, sending first
message, currently sending
message.
6
Blinks On
Blinks
Out of range, first message
sent, currently sending
message.
7
Blinks On
Off
Out of range, first message
sent, not currently sending
message.
8
Blinks Blinks
Blinks
Out of range, sending first
message, currently sending
message.
Cellular status LEDs
The cellular status LEDs are five small LEDs located below the
serial number label on the module.
