12
600-1053-4 Concord 4 CDMA Module Installation Sheet
added again. Clear the device by deleting (excluding) it from its
network.
Note: The Alarm.com module can be used to delete devices in
any network. The device will clear itself and be able to be
added to another network. The device’s old network will still list
that device as part of its network (but the device will not be
able to be controlled by that network) until the device is
removed from its old network.
Specifications
Compatibility
Concord panels with software versions 4.0
and higher
Voltage
12 V nominal, 65 mA (continuous) 1600 mA
(instantaneous peaks) maximum from panel
battery or auxiliary power supply
Inputs
One hardwired zone input
Cellular network
1xRTT CDMA Verizon; 3G HSPA AT&T, T-
Mobile or Rogers
Power/data bus
One four-wire SuperBus auto addressing
power/communication data bus
Indicators
One module/panel communication status
LED, one module power LED, one
automation LED, five wireless
communication status LEDs
Dimensions
5.25 Ч 4.125 Ч 1 in. (133 Ч 105 Ч 25 mm)
Case color
Belgian gray
Case material
High-impact, ABS plastic
Operating temperature
32 to 120ºF (0 to 49ºC)
Storage temperature
-30 to 140ºF (-34 to 60ºC)
Relative humidity
90% noncondensing (maximum)
Regulatory information
FCC
Changes or modifications not expressly approved by UTC Fire
and Security can void the user’s authority to operate the
equipment.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment in to an outlet on a circuit different from that
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with the FCC RF radiation exposure
limits set forth for an uncontrolled environment. This equipment
should be installed and operated with a minimum distance of
20 centimeters between the radiator and your body.
Under Industry Canada regulations, this radio transmitter may
only operate using an antenna of a type and maximum (or
lesser) gain approved for the transmitter by Industry Canada.
To reduce potential radio interference to other users, the
antenna type and its gain should be so chosen that the
equivalent isotropically radiated power (e.i.r.p.) is not more
than that necessary for successful communication.
Conformément à la réglementation d'Industrie Canada, le
présent émetteur radio peut fonctionner avec une antenne d'un
type et d'un gain maximal (ou inférieur) approuvé pour
l'émetteur par Industrie Canada. Dans le but de réduire les
risques de brouillage radioélectrique à l'intention des autres
utilisateurs, il faut choisir le type d'antenne et son gain de sorte
que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne
dépasse pas l'intensité nécessaire à l'établissement d'une
communication satisfaisante.
This device complies with Industry Canada license-exempt
RSS standard(s).
Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must
accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes: (1)
l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur
de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le
fonctionnement.
FCC ID: YL6-143200H5V4 (GSM), YL6-143200C5V4 (CDMA)
IC: 9111A-143200H5V4 (GSM)
Contact information
o
For customer support, see
Copyright © 2013 UTC Fire & Security. All rights reserved
