18









AE MODE: Here you can set the camera exposure mode. It includes: auto/manual/AV (iris priority)/TV

(shutter priority). Please use the left/right button on the keyboard or in the speed dome terminal menu to

set.

o

Auto: It becomes valid after you set the exposure compensation, backlight compensation

(BLC), slow shutter, wide dynamic region (WDR).

o

Manual: It becomes valid after you set the gain setting, shutter, iris setting, wide dynamic

region (WDR).

o

AV: It becomes valid after you set the exposure setting, iris setting, wide dynamic region

(WDR).

o

TV: It becomes valid after you set the shutter setting, exposure compensation, wide dynamic

region (WDR).

GAIN SETTING: The value ranges from 1 to 16. Default value is 2. Please use the left/right button on

the keyboard or in the speed dome terminal menu to set.

SHUTTER: You can set shutter speed here. The value ranges from

1/3 to 1/10000

.

Please use the

left/right button on the keyboard or in the speed dome terminal menu to set.

IRIS SETTING: The value ranges from 1 to 18. Please use the left/right button on the keyboard or in the

speed dome terminal menu to set.

EXPOSURE COM: The value ranges from 1 to 15. Please use the left/right button on the keyboard or

in the speed dome terminal menu to set.

SLOW AE: In the strong light environment, you can lower the camera exposure speed to capture the

image and enhance the definition. The value ranges from 1 to 16. The bigger the value, the higher the

exposure speed. Please use the left/right button on the keyboard or in the speed dome terminal menu

to set.

SLOW SHUTTER: In lower illumination environment, you can lower the cameras auto exposure time to

capture the image and enhance the definition. Please note for the moving object, the image trail

phenomenon may occur. Please use the left/right button on the keyboard or in the speed dome

terminal menu to set.

WDR ENBALE: It is an abbreviation for wide dynamic region. Please make sure your camera supports

current function. This function can adjust the video brightness when the contrast between the strong

light and the dark light is too high. Please use the left/right button on the keyboard or in the speed dome

terminal menu to set.

NEXT PAGE: It includes: BLC, GAIN LIMIT, SLOW SHUTTER LOW LIMIT, NOISE REDUCTION, 3D

NOISE REDUCTION. Move the cursor to the item and then click the left/right button to set.

o

BLC: It is an abbreviation for back light compensation. System can compensate the object in

the dark light to achieve a clear video. Please use the left/right button on the keyboard or in

the speed dome terminal menu to set.

AE MODE : AUTO
GAIN SETTING : 02
SHUTTER : 1/50
IRIS SETTING : 11
EXPOSURE COM : 08
SLOW AE : 01
SLOW SHUTTER ON
WDR ENBALE : OFF
NEXT PAGE
BACK
EXIT

BLC :ON/OFF
GAIN LIMIT : 08
SLOW SHUTTER LIMIT : 1/12
NOISE REDUCTION : 03
3D NOISE CONTROL : ON/OFF
BACK
EXIT
