16
4.4.1.2 Address Information
Move the cursor to SITE INFORMATION and then click confirm button.
ADDR TYPE: There are two options: soft and hard. Please use the left/right button on the keyboard or
in the speed dome terminal menu to set. Please note you need to reboot to activate current setup.
ADDR-HARD: It is an address you set in the dial switch. You can not modify it through software.
ADDR-SOFT: You can set address via software. It is to say, you can use menu to modify dome address.
The value ranges from 0 to 254. Please use the left/right button on the keyboard or in the speed dome
terminal menu to set.
BACK: Go back to the previous menu.
EXIT: Log out system menu.
4.4.2 Display Setting
Move the cursor to DISPLAY SETUP and then click confirm button, you can go to the third submenu. Please
use the left/right button on the keyboard or in the speed dome terminal menu to set. After completed setup,
please click save button to save current setup.
PRESET TITLE: Display dome preset title or not. Please use the left/right button on the keyboard or in
the speed dome terminal menu to set. You can go to Function Setup->Preset section to set
corresponding preset value and preset title.
AZIMUTH DISP: Display dome current coordinates or not. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set
POSITION: Display the angel between the benchmark and then current location. Please use the
left/right button on the keyboard or in the speed dome terminal menu to set.
ZOOM DISP: Display speed dome zoom speed or not. Please use the left/right button on the keyboard
or in the speed dome terminal menu to set.
INSIDE TEMPERATURE: Display dome internal temperature or not. There are three options:
℃
/F/Off.
Please use the left/right button on the keyboard or in the speed dome terminal menu to set.
TITLE DISPLAY: Here you can set to display the speed dome title or not.
BACK: Go back to the previous menu.
EXIT: Log out system menu.
4.4.3 Camera Setting
ADDR TYPE : HARD
ADDR-HARD : 001
ADDR-SOFT : 001
BACK
EXIT
PRESET TITLE ： ON (ON/OFF)
AZIMUTH DISP ： ON (ON/OFF)
POSITION ： OFF (ON/OFF)
ZOOM DISP ： OFF (ON/OFF)
INSIDE TEMP : OFF ( ℃ /FOFF)
TITLE DISP ： OFF (ON/OFF)
BACK
EXIT
