14

ADDR

001-H

BAUD RATE

9600

PARITY

NONE

SOFTWARE

V1.00.0R

BACK
EXIT

SYSTEM INFORMATION
DISPLAY SETTING
CAMERA SETTING
FUNCTION SETTING
IR LIGHT SETTING
EXIT

The above diagram illustrates the overall structure of the speed dome setup menu.

Note:

ERR means current setup is invalid.

Please make sure all the cable connections are right.

4.2

4.2

4.2

4.2

SSSSelf

elf

elf

elf----diagnosis S

diagnosis S

diagnosis S

diagnosis System

ystem

ystem

ystem IIIInformation

nformation

nformation

nformation





After installation, please connect speed dome to power. The system goes on a self-diagnosis, and then it

pops up the above interface to show the system information.

If there is anything wrong during the self-diagnosis, system pops up error code.

The above interface disappears after speed dome received the first command (or the display time lasts for

40 seconds.)

ADDR: Here you can view dome address information. For example, 001-H, 1 is the address number, -H

is hard address mode. –S is software address mode.

Baud rate: Dome communication baud rate.

Parity: Communication parity bit format.

Software: Dome PTZ software version.

When you are using the control keyboard or the matrix host to control the device, please make sure

the control parameter of the keyboard or the matrix host is the same with the speed dome OSD

(including address, baud rate, parity). Please make sure the cable connection is OK.

4.3

4.3

4.3

4.3

Main

Main

Main

Main M

M

M

Menu

enu

enu

enu

You can open the IP dome menu via control keyboard, matrix, or speed dome control terminal.




SYSTEM INFORMATION

Dome self-diagnosis information, address information, set north direction,

language, factory default setup, reboot and so on.

DISPLAY INFORMATION: Display dome preset title, azimuth display, direction, zoom, dome internal

temperature and etc.

CAMERA PARAMETERS

Set camera white balance setup, camera exposure setup, day/night setup,

focus setup, focus limit, zoom speed, digital zoom, aperture setup. The next page includes flip, freeze,

focus sensitivity, stabilization, factory default, reboot and etc.

FUNCTION SETTING

Set preset, pan, auto scan, auto cruise, auto pattern, idle motion and privacy

mask function. The next page includes PTZ speed, initialization position setup, power up, menu idle time,

PTZ auto stop setup, heater setting and etc.

IR LIGHT SETTING: Set dome IR sensitivity, IR light control principle, medium and far light bright, far light
