94
Please refer to the following sheet for monitor window parameter information.
Parameter Function
Display device
information
1: NVR IP address.
2: Channel number.
3: Bit stream.
4: Bit stream decode type.
S1: Overlay.
S2: Off stream.
S3:GD1
H1: Overlay
H2: off stream decoding from the display card.
Digital zoom Click this button and then left drag the mouse in the zone
to zoom in. Right click mouse system restores original
status.
Local record When you click local record button, the system begins
recording. The recorded file is saved to system folder: \
RecordDownload(default).
Snapshot
You can snapshoot important video. All images are
memorized in system folder: \ picture download (default).
Audio
Turn on or off audio.
Close video Close video in current window.
6.2.2 System Menu
System menu is shown as in Figure 6-8.
Please refer to chapter 6.4 Configuration, chapter 6.5 Search, chapter 6.6 Alarm, chapter 6.7
About, chapter 6.8 Log out for detailed information.
Figure 6-8 System Menu
6.2.3 Monitor Window Switch
The monitor window switch interface is shown as in Figure 6-9.
Figure 6-9 Monitor Window Switch
System supports 1/4-window real-time preview.
---- It is video quality adjustment button. It has relationship with decode via software.
--Fluency button. You can use this function to adjust the priority between real-time and
fluency.
6.2.4 PTZ Control
Before PTZ operation, please make sure you have properly set PTZ protocol. (Please refer to
